BS PD IEC TR 62544:2011+A2:2020

This technical report gives general guidance on the subject of active filters for use in highvoltage direct current (HVDC) power transmission. It describes systems where active devices are used primarily to achieve a reduction in harmonics in the d.c. or a.c. systems. This excludes the use of automatically retuned components.

The various types of circuit that can be used for active filters are described in the report, along with their principal operational characteristics and typical applications. The overall aim is to provide guidance for purchasers to assist with the task of specifying active filters as part of HVDC converters.

Cross References:
IEC 60633
IEC/TR 62543
IEC 61000
IEC 61975
IEC/TS 60071-5
IEEE 519
IEC TR 62001-1:2016
IEC TR 62001-3:2016
IEC TR 62001-2:2016
IEC TR 62001-4:2016
IEC 62747


Incorporates the following:
Amendment, February 2020; Amendment, April 2016
