BS PD ISO/TS 13399-204:2016

BS PD ISO/TS 13399-204:2016 specifies a concept for the design of cutting items, limited to any kind of replaceable inserts for reaming, using related properties and domains of values.

This part of ISO 13399 specifies a common way of designing simplified models that contain the following:

• definitions and identification of the design features of replaceable inserts for reaming, with a link to the properties used;
• definitions and identification of the internal structure of the 3D model that represents the features and the properties of replaceable inserts for reaming;

The following are outside the scope of this part of ISO 13399:

• applications where these standard data may be stored or referenced;
• creation and exchange of simplified 3D models for cutting tools;
• creation and exchange of simplified 3D models for tool items;
• creation and exchange of simplified 3D models for other cutting items not described in this part of ISO 13399;
• creation and exchange of simplified 3D models for adaptive items;
• creation and exchange of simplified 3D models for assembly items and auxiliary items.

Cross References:
ISO/TS 13399-2
ISO/TS 13399-80
ISO 13399-1
ISO/TS 13399-3
ISO/TS 13399-5
ISO/TS 13399-50
ISO/TS 13399-70
ISO/TS 13399-100
ISO/TS 13399-150


All current amendments available at time of purchase are included with the purchase of this document.
