BS PD ISO/TS 17519:2019

This document specifies the minimum requirements for the material, design construction and workmanship, manufacturing processes, examination and testing at time of manufacture of an assembly of permanently mounted composite tube(s) in a frame with associated components.

Tubes covered by the requirements of this document are:

a) of composite construction, permanently mounted in a transport frame and suitable for specified service conditions, designated as:
1) Type 3 — a fully wrapped tube with a seamless metallic liner and composite reinforcement on both the cylindrical part and the dome ends; or
2) Type 4 — a fully wrapped tube with a non-load sharing liner and composite reinforcement on both the cylindrical part and the dome ends.

b) with water capacities from 450 l up to and including 10 000 l;

c) containing compressed gases but excluding:
1) liquefied gases,
2) dissolved gases, and
3) gases and gas mixtures which are classified for transport as toxic or oxidizing;

d) with working pressure up to 1 000 bar.

This document does not address tubes with working pressure times water capacity (p × V) more than 3 000 000 bar·l.

Cross References:
NACE/TM 0177-2016
ISO 10286
ISO 11114-1
ASTM D2794
ISO 9809-3
ISO 2808
ISO 13769
ISO 10156
ISO 9809-1
ASTM D522
ISO 9227
ISO 4624
ISO 527-2
ISO 10298
ASTM D1308
ASTM D3170
ISO 9809-2
ASTM G154
ISO 14456
ISO 11114-2
ISO 306
ASTM D3418
ISO 13341
ASTM D4814
ISO 14130
ISO 1496-3:1995 (R07) Ed 4
ISO 11120:2015
ISO 7866:2012/COR 1:2014
ISO 11439:2013
EN 12245:2009
CSA/ANSI NGV 2-2016
ISO 14623
ISO/TR 13086-1
ISO 11515
ISO 11119
DNV GL. DNV -OS -C501: 2013
ANSI. AIAA S-081A-2006
ASME STP-PT-014


All current amendments available at time of purchase are included with the purchase of this document.
