IEEE 1149.7-2009

The standard will define a link between IEEE 1149.1 interfaces in Debug and Test Systems (DTS) and IEEE 1149.1 (JTAG) interfaces in Target Systems (TS). The link defined by this standard introduces an additional layer between these legacy interfaces. This layer may be viewed as an adapter that provides new functionality and features while preserving all elements of the original IEEE 1149.1 (JTAG) interfaces. The standard will define the link behavior (including timing characteristics of signals), protocols, and functionality of the adapters deployed within the DTS and TS. The standard will not modify or create inconsistencies with IEEE 1149.1 (JTAG). The standard will define a superset of the IEEE 1149.1 specification and achieve compliance with IEEE Std 1149.1TM-2001.
