PIP STF05121

Anchor Fabrication and Installation Into Concrete [Complete Revision]

Process Industry Practices, 06/01/2017

Publisher: PIP

File Format: PDF

$136.00$272.94


Published:01/06/2017

This Practice provides details and requirements for anchor fabrication and installation into concrete. Anchors are anchor rod assemblies that include a rod threaded at the two ends, nuts, washers, and anchor plates and/or sleeves if required. J-bolts and L-bolts are not included. Three standard lengths are shown for each diameter anchor rod in both U.S. Customary units and Metric (SI) units.

This Practice also provides requirements for non-standard anchor rod lengths.
