IPC 2222B

Sectional Design Standard for Rigid Organic Printed Boards

Association Connecting Electronics Industries, 10/01/2020

Publisher: IPC

File Format: PDF

$73.00$147.00


Published:01/10/2020

Pages:36

File Size:1 file , 1.3 MB

Note:This product is unavailable in Russia, Ukraine, Belarus

IPC 2222B is intended to provide information on the detailed requirements for organic rigid printed board design. All aspects and details of the design requirements are addressed to the extent that they can be applied to the unique requirements of those designs that use organic rigid (reinforced) materials or organic materials in combination with inorganic materials (metal, glass, ceramic, etc.) to provide the structure for mounting and interconnecting electronic, electromechanical, and mechanical components.
